Energy Storage Battery_Shenzhen Mottcell New Energy Technology Co., Ltd.

Model	Capacity	Capacity(Wh)	BMS (Optional)	Charging/Discharging Current	Instantaneous Current (3-5s)	Recommended Charging Current	Max Continuous Operating Current(A)	Housing Material	Dimensions(mm)
SMG1206	5Ah	76.8	4S Hardware	0~6A	10A	0.5c	6	ABS	L150W65H94
SMG1212	10Ah	153.6	4S Hardware	0~12A	20A	0.5c	12	ABS	L150W97H100
SMG1250BE	50Ah	640	4S Hardware 4S Software	0~50A	100A	0.5c	50A	ABS	L197W132H175
SMG1250PLUS	50Ah	640	4S Hardware 4S Software	0~50A	100A	0.5c	50A	ABS	L196W167H170
SMG12100mini	100Ah	1280	4S Hardware 4S Software	0~100A	300A	0.5c	100A	ABS	L260W168H215
SMG12100BE	100Ah	1280	4S Hardware 4S Software	0~100A	300A	0.5c	100A	ABS	L332W172H220
SMG12100PLUS	100Ah	1280	4S Hardware 4S Software	0~100A	300A	0.5c	100A	ABS	L300W194H197
SMG12200BE	200Ah	2560	4S Hardware 4S Software	0~200A	600A	0.5c	200A	ABS	L531W206H217
SMG12200PLUS	200Ah	2560	4S Hardware 4S Software	0~200A	600A	0.5c	200A	ABS	L556W240H298
SMG12300BE	300Ah	3840	4S Hardware 4S Software	0~300A	600A	0.5c	300A	ABS	L522W238H221
SMG12300PLUS	300Ah	3840	4S Hardware 4S Software	0~300A	600A	0.5c	300A	ABS	L382W193H250
SMG12400	400Ah	5120	4S Hardware 4S Software	0~200A	600A	0.5c	200A	ABS	L522W269H221
SMG12600	600Ah	7680	4S Hardware 4S Software	0~300A	600A	0.5c	200A	ABS	L635W244H222
SMG24100	100Ah	2560	8S Hardware 8S Software	0~100A	300A	0.5c	100A	ABS	L531W206H217
SMG24200	200Ah	5120	8S Hardware 8S Software	0~200A	600A	0.5c	200A	ABS	L523W269H222
SMG36100	100Ah	3840	12S Hardware 12S Software	0~200A	600A	0.5c	200A	ABS	L522W269H221
SMG48100	100Ah	5120	16S Hardware 16S Software	0~200A	400A	0.5c	100A	ABS	L523W269H222

Learn More
